Mini DDC Pump and Reservoir Combo with 5V ARGB | Bykski B-TANK-DDC-MI
stars, based on ( 1 ) reviews
FormulaMod Official Store
Bykski · B-TANK-DDC-MI
Mini DDC Pump and Reservoir Combo
The Bykski B-TANK-DDC-MI combines a DDC pump and a clear acrylic reservoir in one unit for a custom PC water-cooling loop. The pump circulates coolant through the loop, and the reservoir gives you a place to fill it. The compact assembly connects to the loop through G1/4 ports.
Fits
G1/4 fittings
Pump control
PWM
Lighting
5V ARGB
Fits / Use With
- ✓G1/4 fittings for the coolant loop
- ✓A 5V 3-pin ARGB motherboard header for lighting
Not compatible:
- ✗12V 4-pin RGB headers for this lighting version
Key Specifications
| Model | B-TANK-DDC-MI |
|---|---|
| Pump type | Integrated DDC |
| Reservoir | Clear PMMA acrylic |
| Outer pump housing | Aluminum alloy |
| Dimensions (W × D × H) | 62 × 62 × 102.6 mm |
| Port thread | G1/4 |
| Pump connections | Large 4-pin peripheral power and separate 4-pin PWM signal |
| Motherboard lighting header | 5V 3-pin ARGB (RBW) |
What's in the Box
1 × DDC pump and reservoir assembly
Installation & Use
1
Secure the assembly with a compatible pump mount and leave room to reach the top of the reservoir.
2
Connect the assembly to your loop with G1/4 fittings.
3
Fill the reservoir before powering the pump. During bleeding, top up the reservoir as the coolant level drops.
4
Leak-test with only the pump powered. Check the fittings and joints before powering the rest of the PC.
FAQ
Do I need a separate reservoir?
The assembly already includes a clear acrylic reservoir.
Does the PWM header power the pump?
Connect the large 4-pin power plug to the power supply. The separate PWM lead carries the speed-control and feedback signals.
Notes
- Never run the pump dry.
