Barrow

10x16mm / 10x13mm Soft Tube Fitting Kit – Barrow BA-STKA, G1/4

stars, based on ( 0 ) review
items available
Contact Us
FormulaMod Official Store
Barrow · BA-STKA

Soft tube fitting kit for custom PC water cooling

The Barrow BA-STKA is a soft tube fitting kit for connecting G1/4 components in a custom PC water cooling loop. Choose the version that matches your tubing’s nominal inner and outer diameters. The kit includes soft tubing, straight compression fittings, 90° adapters for turns at the ports, and stop plugs for unused ports.

Fits
10 × 13 or 10 × 16 mm soft tubing (nominal)
Port thread
G1/4
Adapters
90° male to female
Tubing
3 m total

Use With

Check the port thread and your tubing’s nominal ID and OD before ordering.

  • ✓G1/4 female ports on custom-loop components
  • ✓BA-STKA-13 for soft tubing with a nominal ID × OD of 10 × 13 mm
  • ✓BA-STKA-16 for soft tubing with a nominal ID × OD of 10 × 16 mm

Design Highlights

Barrow BA-STKA black straight compression fittings arranged in two rows

Straight compression fittings

The threaded collar tightens over the tube after it is seated on the fitting barb. Match the collar to the tube’s outer diameter so it grips the tubing wall.

Barrow BA-STKA white 90° adapters and stop plugs

Make turns and close unused ports

Thread a straight compression fitting into the female side of a 90° adapter to turn the tube run at the port. Fit a stop plug to any unused G1/4 port you need to close.

Key Specifications

ModelBarrow BA-STKA
Tubing typeSoft tubing
Nominal tubing size (ID × OD)10 × 13 mm or 10 × 16 mm
Component port threadG1/4
Elbow connection90° G1/4 male to G1/4 female
Fitting finishesBlack, White, Silver, Gold
Barrow BA-STKA gold compression fittings, 90° adapters, and stop plugs

Gold finish shown.

Which Version Do I Need?

Choose by what you need to connect and what you already have.

Barrow BA-STKA Fitting KitTHIS PAGE
Choose this kit if you need soft tubing, straight compression fittings, 90° adapters, and stop plugs for the same build.
Choose the 4- or 8-piece pack if you already have tubing and only need straight fittings. Match the fittings to your tubing size.

What's in the Box

8 × G1/4 straight soft tube compression fittings2 × G1/4 male-to-female 90° adapters2 × G1/4 stop plugs3 m total of soft tubing
Barrow BA-STKA silver fitting set with straight connectors, elbows, and plugs laid out in rows

Fittings shown in silver.

Installation & Use

1
Plan the tube runs and cut the soft tubing square. Leave enough length to avoid kinking at bends.
2
Fit the compression fittings to your G1/4 ports. Where a run needs to turn at a port, install a 90° adapter first and thread the compression fitting into it. Plug any unused ports.
3
Unscrew the compression collar and slide it over the tube with the threads facing the fitting. Push the tube fully onto the barb, then thread the collar back onto the fitting and tighten it.
4
Follow your loop components’ instructions to fill and leak-test the loop before powering the PC.

To complete the loop, supply the water block, radiator, pump, reservoir, and coolant.

FAQ

Can I use the same fitting for 10 × 13 and 10 × 16 mm soft tubing?

Choose the fitting that matches your tubing’s nominal ID × OD: 10 × 13 mm or 10 × 16 mm.

Can I use these fittings with 16 mm hard tubing?

The 10 × 16 mm fittings are designed to clamp flexible tubing over a barb. Use hard-tube fittings for rigid tubing.

How many fittings come with the kit?

The kit includes eight straight compression fittings, two 90° adapters, and two stop plugs.

What thread do the elbows use?

Each elbow has one G1/4 male thread for a component port and one G1/4 female thread for a fitting.

Can I order the fittings in gold?

Gold is available in both tube sizes, along with black, white, and silver.

Notes
  • The color between different kind of Fitting might have difference. (For example, the gold color for tube fitting might be different with the gold color of 90 degree fitting.)
  • Due to the difference between different monitors, the color of pictures and the real object will be slightly different.
  • In case of upgrading to the appearance and structure, no further notice, the real object shall prevail.
