Bykski B-DP-6WAY-X POM 6-Way Bridge / Series Distribution Module, G1/4 Ports
Bykski B-DP-6WAY-X POM 6-Way Bridge / Series Distribution Module, G1/4 Ports
TL;DR: The B-DP-6WAY-X is a POM (acetal) fluid-distribution body that consolidates the inter-component plumbing of a custom water loop into a single rigid bridge. It exposes a row of G1/4 BSPP ports that can be plumbed to chain up to six components in series, replacing several short tube runs and elbow...
Common Applications
The B-DP-6WAY-X is a POM (acetal) fluid-distribution body that consolidates the inter-component plumbing of a custom water loop into a single rigid bridge. It exposes a row of G1/4 BSPP ports that can be plumbed to chain up to six components in series, replacing several short tube runs and elbow stacks with a single straight conduit. Inlet and outlet direction can be set horizontal or vertical to suit the chassis layout. The body is solid black POM, chosen for its long-term coolant compatibility and dimensional stability under continuous flow.
Frequently Asked Questions
Q: How many components can this module link?
A: Up to six in a series chain. Each port mates with a standard G1/4 BSPP fitting.
Q: What thread size are the ports?
A: G1/4 BSPP, the same thread used on every Bykski block, radiator and reservoir.
Q: Are fittings included?
A: No. The module ships as the POM body and plugs only. Fittings are sold separately so the builder can match the chosen tubing size and finish.
Q: What material is the body?
A: POM (acetal). Bykski chooses POM for distribution parts because it is dimensionally stable, chemically stable in long-term contact with PC coolant, and resists the creep that affects pure acrylic over time.
Q: Can inlet and outlet direction be reconfigured?
A: Yes. Unused ports are plugged and ports can be selected horizontally or vertically, so the same module can be re-plumbed for a different chassis without buying a new part.
