Bykski AU-RD240-CU-V3 240mm Copper Water-Cooling Radiator, 30mm Profile, Dual 120mm Fan Mount, G1/4 Ports
Bykski AU-RD240-CU-V3 240mm Copper Water-Cooling Radiator, 30mm Profile, Dual 120mm Fan Mount, G1/4 Ports
TL;DR: The AU-RD240-CU-V3 is a 240mm copper PC water-cooling radiator in a 30mm-thickness profile, which is the depth class most likely to fit front and top mounts on mid-tower cases where a thicker radiator will not clear motherboard heatsinks or memory. The water channels and wave fins are red copper...
Common Applications
The AU-RD240-CU-V3 is a 240mm copper PC water-cooling radiator in a 30mm-thickness profile, which is the depth class most likely to fit front and top mounts on mid-tower cases where a thicker radiator will not clear motherboard heatsinks or memory. The water channels and wave fins are red copper while side panels are iron and do not contact coolant. The footprint accepts two 120mm fans on the standard 240 pattern, and two G1/4 inch ports allow installation in either flow direction. Typical applications are single-CPU loops, a light CPU plus GPU loop, or a secondary radiator added to an existing loop.
Frequently Asked Questions
Q: How thick is the radiator?
A: 30mm, the slim depth class for top and front mounts in mid-towers.
Q: How many fans does it support?
A: Two 120mm fans on the standard 240 pattern. Push-pull is possible if the case provides clearance on both sides.
Q: What are the materials?
A: Red copper water channels and wave fins, with iron side panels that do not contact coolant.
Q: What thread size are the ports?
A: Two G1/4 inch ports, the standard for PC water-cooling fittings.
Q: Is it appropriate for a CPU plus GPU loop?
A: It handles a single CPU loop comfortably and a light CPU plus GPU loop, but heavy multi-block loops benefit from adding a second radiator or stepping up to a thicker or 360mm unit.
